Small timber garage
Small timber garage Small timber garage for sale Small timber garage for sale Small timber garage for sale

Chester workshop 2.8m x 4.8m

Be the first to review this product

£4,802
calculator-iconcalculator-iconcalculator-iconcalculator-iconcalculator-iconcalculator-icon

Novuna Finance Calculator

-- Please Select --
  • -- Please Select --
  • 45mm
  • 60mm + £1,333
  • Black + £411
  • Red & Black + £411
  • Green & Black + £411
  • None
- +



Get a full quote for this product from our expert team:



Free Nationwide Delivery

Quick Specification

  • Ridge Height: 2.52m
  • Eaves Height: 2.08m
  • Depth: 4.8
  • Length: 2.8 m
  • Wall Thickness: 45mm double tongue and groove
  • Thickness: 45mm-60mm
  • Width: 2.8m
  • Depth: 4.8m
  • Ridge Height: 2.52m
  • Eaves Height: 2.08m

Chester workshop 2.8m x 4.8m

£4,802

Overview

The Chester Timber Workshop provides the ideal personal space for any DIY project. Small enough for almost any garden, yet functional enough for almost any project (not to mention competitively priced), it’s the perfect solution for any self-starter, hobbyist or home improver. It even creates a great base for gardening. Oh, and by the way, it fits a car.



It can also be used as a large wooden workshop comes with sturdy walls of up to 60mm thick double tongue and groove log wall construction, convenient large swing barn doors for bigger projects and a secure side door.



Specification - Chester Log Garage

Wall construction

45 mm or 60mm double tongue & groove interlocking logs

Base construction

Tanalised bearers

Front roof overhang
Side roof overhang
Back roof overhang

0.50 m
0.20 m
0.20 m

Glazing

Single glazed window & Single glazed door



Garage Range



Cabin Dimensions (m)

Doors (cm)

Windows (cm)

Width

Depth

Eaves

Ridge

Wall Thickness

Access

Garage

Chester

2.80

4.80

2.08

2.52

45mm & 60mm

90/185

Doors 200/191

1 x 80/88

Hexham

3.60

5.16

2.65

Doors 252/191

2 x 80/88

Southwell

3.80

5.60

2.77

Leicester

4.50

5.50

Salisbury

4.80

6.80

2.91

Warwick

4.80

9.80

Hereford

5.70

5.70

Brighton

7.50

6.50

2.21

3.38

2 x Doors 252/191

Optional

Worcester

10.5

5.50

2.34

3.32

2 x 70/94

Thirsk

6.80

6.00

4.42

5.37

6 x 80/94

Like all Logspan log cabins, the timber used in manufacture is sustainably grown Northern spruce. It is important to note, all cabins come with a treated base frame so this protects the bottom of the cabin but the rest of the timber MUST be treated as soon as possible. As wood is a natural material; it expands, moves and contracts all the time so it is important that the timber is treated properly and as soon as possible. It is worth treating inside cabins as well before you fit it out.

Specifications

General

SKU
CHESTER
Shape
Rectangular
Roof Style
Apex
Timber
Slow grown Scandinavian spruce
Base construction
Tanalised floor bearers & base frame
Dimensions

Width
2.8 m
Depth
4.8
Ridge Height
2.52m
Eaves Height
2.08m
Roof overhang (Front & Side/Back)
0.50 m & 0.20 m
Timber Thickness

Wall Thickness
45mm double tongue and groove
Wall U-Value
1.937 W/(m²K)
Floor
20 mm tongue and groove boards
Roof
20 mm tongue and groove boards
Windows & Doors

Glazing
Single glazed 4mm glass
Opening Windows
2 windows
Window Sizes
1 - 0.80m x 0.88m
Exterior Doors
1 double garage door & 1 side door with double action euro lock
Door Sizes
2.00m x 1.91m & 0.90m x 1.85m
What's in the kit

What's in the box

What's included in the package is everything you need to get going:

- A treated base frame on which the whole cabin is built
- All wall logs, each cut to size, length and with the interlocking notches already cut out
- Roof boards cut to length
- Skirting board
- Internal and External Trim
- Wind Boards for the gable ends
- Detailed instructions
- Screws of all lengths and sizes for each section of the job (this is a generic screw pack/you are likely to have some left over)
- Nails for putting down floor - (some like to use a brad gun instead of our nails to make 'secret nailing' in the tongue & groove boards easier)
- Roof covering - you can opt to order with or without the roof covering - This is selected at time of order
- If you have any trouble, we are available on the end of the phone to help out with build or with any queries.
- There is also most likely to be an extra wall board with notches cut out. This is there if there are any damages or missing parts. This extra log can be used to replace the broke or missing part in the unlikely circumstance. If you don't use it, it's a free piece of wood which could be used to make a shelf or a little step for the cabin.

The only thing you will need is your own tools and a flat, stable, level base. Information and advice on base work can be found here. It is also advisable to have at least 2 able bodies to build the cabin.

Plans

pdf
(Size: 98.4 KB)
Chester Garage Plan
